Emerson KJ3222X1-BK1 Analog Input Modules Fast Shipping!

FAQ

In which systems is this module used?
This module is used in Emerson DeltaV S-Series control systems to convert analog signals from field devices into digital signals for processing.

What input signal types does the module support?
It supports 4–20 mA analog input signals and is compatible with the HART protocol, suitable for various field devices.

What is the operating temperature range of the module?
The operating temperature range is from -40 °C to +70 °C, suitable for diverse industrial environments.

What are the dimensions and weight of the module?
The module dimensions are 125 mm × 60 mm × 35 mm, and it weighs 0.2 kg, facilitating easy installation and maintenance.

What are the power requirements for the module?
The module requires a 12 VDC local bus power supply at 150 mA and a 24 VDC field bus power supply at 300 mA.

What is the protection rating of the module?
The module has an IP20 protection rating, suitable for rack-mounted installations in industrial environments.

Does the module support HART protocol?
Yes, the module supports the HART protocol, allowing digital signals to be superimposed on the analog loop for device configuration and diagnostics.

Is this module suitable for hazardous environments?
Yes, the module complies with ATEX directives, suitable for II 3G Ex nA [nL] IIC Gc and II 3G Ex ec [ic] IIC Gc hazardous environments.
