Bently Nevada 330104-07-12-10-02-CN 8 mm 3300 XL Eddy-Current Proximity Probe Original

Bently Nevada 330104-07-12-10-02-CN 8 mm 3300 XL Eddy-Current Proximity Probe Original

0.0

Points

100% Original and Authentic.
100% Brand New, Ready to ship.
Support Refund, 7X24h Service.
1-Year Warranty on All Products.

Today's Discount: 90% 00 : 00 : 00

Low stock: 48 left

32%

Add to cart

Product Details

Bently Nevada provides good Condition Monitoring and Machine Asset Protection. Power Supply, CPU, I/O Modules, Proximitor Sensor and Programming cable of 3500/33 are supplied.

Product Introduction

Bently Nevada 330104-07-12-10-02-CN 8 mm 3300 XL Eddy-Current Proximity Probe Original

Brand：Bently Nevada

Item No.：330104-07-12-10-02-CN

Product Type：8 mm 3300 XL Eddy-Current Proximity Probe

Product Origin：USA

Dimensions：120 mm case length; 8 mm probe tip diameter

Weight：0.80 kg (with 1.0 m armored cable)

Payment：T/T, Western Union, Credit Card

Shipping Port：Xiamen, China

Lead Time：1-3 Days

Condition：Brand New And Original

Warranty：1 Year

Compliant import, support for testing, fast response to after-sales service

Sufficient inventory of tens of thousands of models, fast delivery of spot goods, welcome to consult!

Product FAQs

We've listed some product-related issues below. If you need further information or technical support, please contact us via email or by submitting a form. We'll get back to you as soon as possible!

FAQ

What is the main application of the 330104-07-12-10-02-CN probe?
It is commonly used for non-contact monitoring of shaft vibration, displacement, and position in rotating machinery such as compressors and turbines.

What do the model number segments represent?
07 = 7 mm unthreaded length, 12 = 120 mm case length, 10 = 1.0 m system length, 02 = armored miniature coax connector, CN = Chinese certification.

What materials are used for this probe?
The probe tip is made of PPS, and the housing is stainless steel with armored cabling.

What is the operating temperature capability?
It functions within –52 °C to +177 °C.

Which proximitor is compatible with this probe?
It is designed to work with the 3300 XL Proximitor for accurate shaft vibration and displacement measurements.

Does this probe include certification?
Yes, the “CN” suffix indicates Chinese certification.

What is the typical sensitivity of this probe?
It provides roughly 200 mV/mil with a usable linear range from 0.25 to 2.5 mm.

What are the physical dimensions and weight?
The probe has a 120 mm case length, 8 mm tip diameter, and weighs about 0.80 kg including the 1.0 m armored cable.
