What types of input signals does the F3AD08-5R support?
The module supports only voltage input signals in the ranges 0–5 V DC, 1–5 V DC, 0–10 V DC, and -10–10 V DC. Current signals require conversion through external resistors.

How is the isolation implemented in the F3AD08-5R module?
Optical isolation is used between the input terminals and the internal circuitry to protect the PLC and ensure signal integrity.

What is the resolution of the analog-to-digital conversion?
The module features a 16-bit A/D converter, allowing high-precision signal measurement.

Can the module handle both single-ended and differential inputs?
The module is designed specifically for differential voltage inputs to minimize noise and improve measurement accuracy.

What are the temperature effects on measurement accuracy?
Accuracy is ±0.1% of full scale at 23 ±2°C and ±0.2% of full scale over the operating range of 0–55°C.

How fast can the F3AD08-5R perform conversions?
Conversion speed can be selected between 50 μs and 100 ms per module depending on system requirements.

What is the maximum common mode voltage allowed?
The maximum common mode voltage is ±1 V DC for the -10–10 V and 0–10 V input ranges.

What is the physical size and weight of the module?
The module measures 28.9 × 100 × 106.1 mm and weighs 0.2 kg, making it compact for integration into FA-M3 PLC systems.
