Name: Yokogawa ASI133-H00/ATSA3S Current Input Module (Isolated) Unbelievable Prices!
Brand: Yokogawa Electric
SKU: 4208
Availability: InStock
Rating: 5.0 (1 reviews)

Product Details

Yokogawa Electric has over 100 years experience in the measurement and control business,it produces the first DCS in the world. The main system is CENTUM CS 3000 R3.

Product Introduction

Yokogawa ASI133-H00/ATSA3S Current Input Module (Isolated) Unbelievable Prices!

Brand：Yokogawa

Item No.：ASI133-H00/ATSA3S

Product Type：Current Input Module

Product Origin：Japan

Dimensions：130 x 107.5 x 32.8 mm

Weight：0.3 kg

Payment：T/T, Western Union, Credit Card

Shipping Port：Xiamen, China

Lead Time：1-3 Days

Condition：Brand New And Original

Warranty：1 Year

Compliant import, support for testing, and fast response to after-sales service

Flexible stock of various models, support for rapid response, welcome to cooperate and communicate!

Product FAQs

We've listed some product-related issues below. If you need further information or technical support, please contact us via email or by submitting a form. We'll get back to you as soon as possible!

FAQ

What isolation method is used in the ASI133-H00/ATSA3S module?
The module employs channel-to-channel and channel-to-system isolation to prevent signal interference and ensure intrinsic safety in hazardous environments.

What is the maximum input current the module can safely handle?
The module can handle up to 22.5 mA per channel without affecting accuracy or causing damage.

How fast is the data acquisition from input signals?
The module updates input data every 10 ms, and its step response time is 100 ms.

What is the accuracy of the current measurement?
The module provides an accuracy of ±16 µA across the entire input range.

Can the module provide power to connected transmitters?
Yes, it can supply a transmitter power voltage of ≥16 V DC with a maximum output current of 20 mA.

How does ambient temperature affect the measurement?
The typical drift due to ambient temperature changes is ±16 µA per 10 °C.

What type of connection terminals are used for field wiring?
Pressure clamp terminals (ATSA3□) are used for secure and reliable field connections.

Is HART communication supported on this module?
Yes, the module supports HART communication for configuration and diagnostics.
