Honeywell Experion PKS ( C200, C300 ) is one of the most important DCS system. Original New Control processor, Control Interface, Redundancy Module, I/O Link Interface Module, PM I/O, FTA, FSC Module, UCN Board are provided

Product Introduction

Honeywell 900G02-0001 ControlEdge HC900 Digital Input Module Unbelievable Prices!

Brand：Honeywell

Item No.：900G02-0001

Product Type：Digital Input Module

Product Origin：USA

Dimensions：137 x 35.6 x 151.7 mm

Weight：0.354 kg

Payment：T/T, Western Union, Credit Card

Shipping Port：Xiamen, China

Lead Time：1-3 Days

Condition：Brand New And Original

Warranty：1 Year

Formal channels, complete test instructions, responsive service

Sufficient inventory of tens of thousands of models, fast delivery from stock, welcome to consult!

Product FAQs

We've listed some product-related issues below. If you need further information or technical support, please contact us via email or by submitting a form. We'll get back to you as soon as possible!

FAQ

What type of input does the 900G02-0001 module support?
It supports digital DC voltage input using a sinking (low-side switching) configuration.

How many input channels are available on the module?
The module provides 16 input channels, organized into two electrically isolated groups of 8.

What is the acceptable input voltage range?
The input voltage range is 10 to 32 VDC, with a peak tolerance of 32 VDC.

What voltage thresholds define ON and OFF states?
The ON voltage must be at least 9.5 VDC, and the OFF voltage must be 3.5 VDC or less.

Is channel-to-channel isolation provided on the module?
Yes, the module provides galvanic isolation for each group of 8 channels to the controller logic.

What is the response time for input state changes?
The OFF-to-ON and ON-to-OFF response times are both less than or equal to 4 milliseconds.

What are the power requirements for the module?
The module requires 5VDC power with a maximum current of 130mA. It does not require 24VDC power.

What are the module’s physical dimensions and weight?
The module measures 137 x 35.6 x 151.7 mm and weighs 0.354 kg.
