Name: GE IC695ALG106 PACSystems RX3i Isolated Analog Input Module 30-Day Returns！
Brand: GE Fanuc PLC
SKU: 6460
Availability: InStock
Rating: 5.0 (1 reviews)

0.0

Points

100% Original and Authentic.
100% Brand New, Ready to ship.
Support Refund, 7X24h Service.
1-Year Warranty on All Products.

Today's Discount: 90% 00 : 00 : 00

Low stock: 130 left

87%

Add to cart

Product Details

GE Fanuc PLC system includes IC200, IC693, IC694, IC695, IC697, IC698, and Cards series IS200, IS215, DS200,DS3000/3800 and more.

Product Introduction

GE IC695ALG106 PACSystems RX3i Isolated Analog Input Module 30-Day Returns！

Brand：GE Fanuc

Item No.：IC695ALG106

Product Type：Isolated Analog Input Module

Product Origin：USA

Dimensions：34 x 140 x 145 mm

Weight：0.25 kg

Payment：T/T, Western Union, Credit Card

Shipping Port：Xiamen, China

Lead Time：1-3 Days

Condition：Brand New And Original

Warranty：1 Year

Original import channel supply, support testing instructions, worry-free after-sales

A wide range of spot models, support quick docking of procurement needs, welcome to inquire!

Product FAQs

We've listed some product-related issues below. If you need further information or technical support, please contact us via email or by submitting a form. We'll get back to you as soon as possible!

Frequently Asked Questions (FAQ)

What type of input signals does the IC695ALG106 support?
It supports both voltage and current signals. Voltage ranges include ±10V, 0–10V, ±5V, 0–5V, and 1–5V. Current ranges include 0–20mA, 4–20mA, and ±20mA.

How many channels are available on this module?
The IC695ALG106 module has 6 fully isolated input channels.

What is the module’s resolution?
It features a 16-bit ADC, and the data can be output as either a 32-bit floating point or integer.

What kind of isolation is provided?
The module provides 250 VAC continuous isolation (1500 VAC for 1 minute) between channels and from the terminal block to the backplane.

Does the module require external power?
Yes, it requires an external isolated +24 VDC power source ranging from 19.2 to 30 VDC.

What CPU firmware version is required?
It requires a PACSystems RX3i CPU with firmware version 5.0 or later.

How accurate is the input measurement?
Accuracy is ±0.1% at 25°C and ±0.2% across the full operating temperature range.

How often should the module be calibrated?
It is recommended to calibrate the module every 12 months to maintain accuracy.
