Product Details

Schneider aims to bring Sustainability and Efficiency for all. Modicon Quantum system is the advanced PLC system.

Product Introduction

Schneider 170AMM09000 Analogue Discrete I/O Base 30-Day Returns！

Brand：Schneider

Item No.：170AMM09000

Product Type：Analogue Discrete I/O Base

Product Origin：France

Dimensions：47.5 x 125 x 141.5 mm

Weight：0.24 kg

Payment：T/T, Western Union, Credit Card

Shipping Port：Xiamen, China

Lead Time：1-3 Days

Condition：Brand New And Original

Warranty：1 Year

Compliant imports, support for cooperative testing, and fast response to after-sales service

Tens of thousands of models in stock are sufficient, and stocks are shipped quickly. Welcome to consult!

Product FAQs

We've listed some product-related issues below. If you need further information or technical support, please contact us via email or by submitting a form. We'll get back to you as soon as possible!

Frequently Asked Questions (FAQ)

What types of analog input signals are supported by the 170AMM09000 module?
It supports ±10V, ±5V, ±20mA, 1–5V, and 4–20mA differential inputs.

What is the maximum load for the analog outputs?
Up to 600Ω for current output and at least 3kΩ for voltage output.

Does the discrete output have short-circuit protection?
Yes, it includes short-circuit and overload protection for discrete outputs.

Is there input overvoltage protection on the analog channels?
Yes, analog inputs are protected against -50 to +50V for short durations.

What type of discrete output does this module provide?
It uses transistor outputs with positive logic.

What applications is the 170AMM09000 suited for?
It is commonly used in infrastructure, energy systems, material handling, and simple machine control.

What is the analog conversion accuracy?
Up to ±0.35% at 25°C for outputs; analog input accuracy can be as fine as 0.0016.

What is the operating temperature range of the module?
The module operates reliably between 0°C and 60°C.
