ABB SDCS-FEX-1 3ADT306000R1 Field Excitation Board 30-Day Returns！

Brand：ABB

Item No.：SDCS-FEX-1 3ADT306000R1

Product Type：Field Excitation Board

Product Origin：Sweden (SE)

Dimensions：83 x 44 x 133 mm

Weight：0.1 kg

Payment：T/T, Western Union, Credit Card

Shipping Port：Xiamen, China

Lead Time：1-3 Days

Condition：Brand New And Original

Warranty：1 Year

Regular channels, complete test instructions, and responsive services

Large stock, diverse series, adapted to different working conditions, welcome to consult!

Product FAQs

We've listed some product-related issues below. If you need further information or technical support, please contact us via email or by submitting a form. We'll get back to you as soon as possible!

FAQ – Frequently Asked Questions

What is the function of the SDCS-FEX-1 board?
It serves as a single-phase diode rectifier to supply field current for DC motors in DCS 500 systems.

What is the maximum AC voltage the board can handle?
The board can operate with AC input voltages from 110 V (-15%) up to 500 V (+10%).

How is the board mounted?
It must be installed inside the armature converter module and mechanically fixed beside the SDCS-POW-1 unit.

What is the board’s method for adjusting field current?
Field current can be slightly adjusted using an external resistor in series with the field winding.

What does the board’s power loss look like under rated conditions?
The power loss at rated DC output current is less than or equal to 10 W.

Is the SDCS-FEX-1 compatible with 690 V transformers?
No, the board is rated for a maximum isolation voltage of 600 V, so 690 V transformer inputs are not suitable.

How is current monitoring performed on this board?
Current is monitored via a capacitor and auxiliary rectifier that measures the AC component of the DC output.

What is required for proper electrical connection of the board?
A flat cable connects the SDCS-FEX-1 to SDCS-CON-2 via terminal X14.
