Honeywell Experion PKS ( C200, C300 ) is one of the most important DCS system. Original New Control processor, Control Interface, Redundancy Module, I/O Link Interface Module, PM I/O, FTA, FSC Module, UCN Board are provided

Product Introduction

Honeywell FC-TSDO-0824 Safety Manager System Digital Output FTA Fast Shipping!

Brand：Honeywell

Item No.：FC-TSDO-0824

Product Type：Digital Output FTA

Product Origin：USA

Dimensions：60 x 70 x 58 mm

Weight：0.5 kg

Payment：T/T, Western Union, Credit Card

Shipping Port：Xiamen, China

Lead Time：1-3 Days

Condition：Brand New And Original

Warranty：1 Year

Original overseas introduction, testing assistance and explanation support, stable and reliable service

Ten thousand models are in stock, quickly matching needs, welcome to call for cooperation!

Product FAQs

We've listed some product-related issues below. If you need further information or technical support, please contact us via email or by submitting a form. We'll get back to you as soon as possible!

Frequently Asked Questions (FAQ)

What is the function of the Honeywell FC-TSDO-0824 module?
The Honeywell FC-TSDO-0824 module is a field termination assembly (FTA) that interfaces between the system interconnection cable and the external field wiring, providing safe digital outputs.

How many output channels does the FC-TSDO-0824 module provide?
The module provides 8 output channels.

What is the maximum continuous current per channel for the FC-TSDO-0824 module?
The maximum continuous current per channel is 1.5 A.

What is the voltage range supported by the FC-TSDO-0824 module?
The module supports a maximum voltage of 36 Vdc.

What is the dimension of the FC-TSDO-0824 module?
The dimensions of the module are 60 × 70 × 58 mm (L × W × H).

What is the maximum wire diameter supported by the screw terminals of the FC-TSDO-0824 module?
The maximum wire diameter is 2.5 mm² (AWG 14).

How should the wiring be installed in the FC-TSDO-0824 module?
The wiring should be installed using the screw terminals, with a stripping length of 7 mm (0.28 in) and a tightening torque of 0.5 Nm (0.37 ft-lb).

What safety certifications does the FC-TSDO-0824 module have?
The module is certified with CE, TUV, UL, CSA, and FM approvals.
