Product Details

Bently Nevada provides good Condition Monitoring and Machine Asset Protection. Power Supply, CPU, I/O Modules, Proximitor Sensor and Programming cable of 3500/33 are supplied.

Product Introduction

Bently Nevada 3500/22M 164466-01 Transient Data Interface Module Trusted supplier

Brand：Bently Nevada

Item No.：3500/22M 164466-01

Product Type：Transient Data Interface Module

Product Origin：USA

Dimensions：241.3 x 24.4 x 241.8 mm

Weight：0.91 kg

Payment：T/T, Western Union, Credit Card

Shipping Port：Xiamen, China

Lead Time：1-3 Days

Condition：Brand New And Original

Warranty：1 Year

Compliant import, support for cooperation testing, and fast response to after-sales service

The model covers a wide range and the delivery is efficient. Welcome to contact us for information!

Product FAQs

We've listed some product-related issues below. If you need further information or technical support, please contact us via email or by submitting a form. We'll get back to you as soon as possible!

Frequently Asked Questions (FAQ)

What is the primary function of the 3500/22M TDI module?
The 3500/22M TDI serves as the interface between the 3500 monitoring system and System 1 or configuration software. It combines rack interface and communication functions.

Can the 3500/22M TDI operate without affecting machine protection?
Yes, the TDI is not part of the critical protection path. It does not impact the machine’s automatic protection functions.

What kind of data does the 3500/22M collect?
It collects steady-state, transient, static, and waveform data, including alarm and startup/coastdown data.

Is a special disk required for transient waveform capture?
Yes, a Channel Enabling Disk must be installed to activate dynamic and transient waveform capture features.

What are the available network connection options for the module?
The module supports both copper (10Base-T/100Base-TX) and fiber optic (100Base-FX) Ethernet interfaces.

How many waveform sampling configurations are supported?
The module supports multiple synchronous sampling configurations ranging from 1024 to 16 samples per revolution and asynchronous spans from 10 Hz to 30 kHz.

Where should the 3500/22M be installed in the rack?
The module must be installed in Slot 1, directly adjacent to the power supplies.

What is the operational temperature range of the 3500/22M TDI?
The module operates within a temperature range of -30°C to +65°C, suitable for harsh industrial environments.
