Name: Yokogawa SNB10d-425/cu2n Safety Node Unit (Rack Mountable Type) Fast Shipping!
Brand: Yokogawa Electric
SKU: 7451
Availability: InStock
Rating: 5.0 (1 reviews)

Product Details

Yokogawa Electric has over 100 years experience in the measurement and control business,it produces the first DCS in the world. The main system is CENTUM CS 3000 R3.

Product Introduction

Yokogawa SNB10d-425/cu2n Safety Node Unit (Rack Mountable Type) Fast Shipping!

Brand：Yokogawa

Item No.：SNB10d-425/cu2n

Product Type： E-mail [email protected] Mobile +8613950166376 Whatsapp +8613950166376 WeChat 13950166376

Manufacturer： Yokogawa

Product Origin：Japan

Dimensions：482.6 x 221.5 x 205 mm

Weight：5.9 kg

Payment：T/T, Western Union, Credit Card

Shipping Port：Xiamen, China

Lead Time：1-3 Days

Condition：Brand New And Original

Warranty：1 Year

Formal channels, complete test instructions, and responsive services

Large stock, diverse series, adapted to different working conditions, welcome to consult!

Product FAQs

We've listed some product-related issues below. If you need further information or technical support, please contact us via email or by submitting a form. We'll get back to you as soon as possible!

Frequently Asked Questions (FAQ)

What type of power input does the SNB10D-425/CU2N support?
The unit supports 100–120 V AC, 220–240 V AC, and 24 V DC inputs, selectable by suffix code.

How many SNB10D units can be connected to one safety controller?
Up to 13 units can be connected using the SEC402 ESB bus coupler; up to 9 units with the SEC401 coupler.

What is the purpose of the CU2N connector unit?
CU2N is a dedicated connector unit for interfacing the SNB10D to the ESB Bus. It ensures reliable communication.

What are the mounting requirements for this unit?
The SNB10D is rack-mounted using four M5 screws and requires insulating bushings (included) for proper installation.

Is the SNB10D suitable for use in explosive environments?
Yes, with the appropriate suffix code “E” and option “/ATDOC,” the unit complies with explosion protection standards.

What standards does this safety node unit conform to?
It complies with ProSafe-RS safety system requirements and is aligned with ISA G3 and explosion protection standards.

What temperature range is supported by the SNB10D-425/CU2N?
With the correct suffix code, it operates reliably in environments from –20 to +70 °C.

Does this unit include any default accessories?
Yes, it comes with four insulating bushings necessary for mounting within the rack system.
