Honeywell FC-TSRO-08UNI Field Termination Assembly Module 100% New

Frequently Asked Questions (FAQ)

What type of outputs does the FC-TSRO-08UNI support?
The module provides 8 relay-based safe output channels, each capable of switching AC or DC loads up to 250 VAC or 250 VDC at a maximum of 2 A.

Is the FC-TSRO-08UNI suitable for SIL3 safety applications?
Yes, it is certified for use in safety-critical applications up to SIL3 according to IEC 61508.

What is the purpose of the conformal coating in the FC-type variant?
The conformal coating provides additional protection against humidity, dust, and other environmental contaminants, ensuring higher reliability in harsh environments.

How are the relays protected in this module?
Each channel includes a fused NO field contact rated at 2 AT (slow-acting) for overcurrent protection.

Can this module be mounted on standard DIN rails?
Yes, it supports mounting on both TS32 and TS35 × 7.5 DIN rails using a universal snap-in mechanism.

What is the expected electrical life of the relays?
The electrical life depends on the switched load but is typically in the range of hundreds of thousands of operations under rated conditions.

What type of terminal connections does the module support?
The module features screw terminals for both signal (2.5 mm² max) and power (16 mm² max) wiring, with specified strip lengths and tightening torques.

Is external power required for operation of the FC-TSRO-08UNI module?
Yes, a common external power supply is connected via screw terminals, shared across all channels.
