HIMA F3 DIO 20/8 02 Safety-Related Controller Remote I/O Module 100% New

HIMA F3 DIO 20/8 02 Safety-Related Controller Remote I/O Module 100% New

0.0

Points

100% Original and Authentic.
100% Brand New, Ready to ship.
Support Refund, 7X24h Service.
1-Year Warranty on All Products.

Today's Discount: 90% 00 : 00 : 00

Low stock: 81 left

54%

Add to cart

Product Details

HIMA provide full solution, including hardware, software, engineering, to ensure safe production processes.

HIMA H41q/H51q Series——MS/HS/HRS(AK6/SIL3)

HIMA Himatrix Series——F20/F30/F31/F35/F60(AK6/SIL3)

Product Introduction

HIMA F3 DIO 20/8 02 Safety-Related Controller Remote I/O Module 100% New

Brand：HIMA

Item No.：F3 DIO 20/8 02

Product Type：Remote I/O Module

Product Origin：Germany

Dimensions：207 x 114 x 66 mm

Weight：1 kg

Payment：T/T, Western Union, Credit Card

Shipping Port：Xiamen, China

Lead Time：1-3 Days

Condition：Brand New And Original

Warranty：1 Year

Formal channels, complete test instructions, responsive service

There are abundant spot models, supporting quick docking of purchasing needs, welcome to inquire!

Product FAQs

We've listed some product-related issues below. If you need further information or technical support, please contact us via email or by submitting a form. We'll get back to you as soon as possible!

FAQ – HIMA F3 DIO 20/8 02

What type of safety certification does the F3 DIO 20/8 02 have?
The module is certified up to SIL 3 (IEC 61508/61511), SIL 4 (EN 50126/50128/50129), and PL e Cat. 4 (EN ISO 13849-1).

Can the F3 DIO 20/8 02 be used in Ex-zone environments?
Yes, it is suitable for installation in Zone 2 as per ATEX requirements when installed in appropriate enclosures.

Is the module compatible with both SILworX and ELOP II Factory?
Yes, compatibility depends on firmware version. SILworX is used for CPU OS V7+, while ELOP II Factory is used for OS up to V6.x.

Can the outputs handle inductive loads?
Yes, but HIMA recommends connecting a protective diode to the actuator to suppress voltage spikes.

What happens during a fault on an input or output?
The module sets the affected channel to a safe (de-energized) state, signals the fault via FAULT LED, and provides error codes.

How are the digital outputs protected from overloads?
Overloaded outputs are automatically shut off and then cyclically checked and reactivated once the fault clears.

Does the device support remote diagnostics?
Yes, diagnostics can be viewed through LEDs and detailed error codes via SILworX or ELOP II Factory.

What is the power supply requirement for this module?
The module operates on 24 VDC ±20% from a PELV/SELV-compliant power source.

If you need more models or deeper comparisons, feel free to ask.
