Product Details

Bently Nevada provides good Condition Monitoring and Machine Asset Protection. Power Supply, CPU, I/O Modules, Proximitor Sensor and Programming cable of 3500/33 are supplied.

Product Introduction

Bently Nevada 3500/15-05-05-02 AC/DC Power Supply Module 12-Month Warranty

Brand：Bently Nevada

Item No.：3500/15-05-05-02

Product Type：AC/DC Power Supply Module

Product Origin：USA

Dimensions：120.7 x 50.8 x 251.5 mm

Weight：1.39 kg

Payment：T/T, Western Union, Credit Card

Shipping Port：Xiamen, China

Lead Time：1-3 Days

Condition：Brand New And Original

Warranty：1 Year

Original imported channel supply, support for testing instructions, worry-free after-sales

A wide range of spot models, support for quick docking of purchasing needs, welcome to inquire!

Product FAQs

We've listed some product-related issues below. If you need further information or technical support, please contact us via email or by submitting a form. We'll get back to you as soon as possible!

FAQ

What is the power input range of the 3500/15 module?

The 3500/15 module accepts universal AC input from 85 to 264 Vac rms, high voltage DC from 88 to 140 Vdc, and low voltage DC from 20 to 30 Vdc.

How many power supplies can be installed in a 3500 rack?

A 3500 rack can accommodate one or two power supplies, providing redundancy for continuous operation.

What is the operating temperature range for the 3500/15 module?

The operating temperature range for the 3500/15 is -30°C to +65°C (-22°F to +150°F).

Can the 3500/15 be used in hazardous environments?

Yes, the 3500/15 meets various hazardous area certifications, including ATEX and IECEx for Zone 2, and Class 1, Division 2.

Is the 3500/15 module compatible with older 3500 power supplies?

No, the 3500/15 is not compatible with legacy power supplies such as the High Voltage AC or Low Voltage AC units.

How does the redundancy feature work in the 3500/15 module?

When two power supplies are installed, the lower one serves as the primary supply, while the upper one serves as a backup. If the primary supply fails, the backup automatically takes over without interrupting operations.

What are the size and weight of the 3500/15 power supply module?

The module measures 120.7 x 50.8 x 251.5 mm and weighs 1.39 kg (3.06 lbs).

Can I install the power supply module without shutting down the system?

Yes, the module can be removed or inserted while the system is powered on, as long as a backup power supply is installed.
