GE IC693ALG223D Series 90-30 PLC Analog Current Input Module 12-Month Warranty

GE IC693ALG223D Series 90-30 PLC Analog Current Input Module 12-Month Warranty

Name: GE IC693ALG223D Series 90-30 PLC Analog Current Input Module 12-Month Warranty
Brand: GE Fanuc PLC
SKU: 7672
Availability: InStock
Rating: 5.0 (1 reviews)

0.0

Points

100% Original and Authentic.
100% Brand New, Ready to ship.
Support Refund, 7X24h Service.
1-Year Warranty on All Products.

Today's Discount: 90% 00 : 00 : 00

Low stock: 94 left

63%

Add to cart

Product Details

GE Fanuc PLC system includes IC200, IC693, IC694, IC695, IC697, IC698, and Cards series IS200, IS215, DS200,DS3000/3800 and more.

Product Introduction

GE IC693ALG223D Series 90-30 PLC Analog Current Input Module 12-Month Warranty

Brand：GE Fanuc

Item No.：IC693ALG223D

Product Type：Analog Current Input Module

Product Origin：USA

Dimensions：51 x 127 x 127 mm

Weight：0.458 kg

Payment：T/T, Western Union, Credit Card

Shipping Port：Xiamen, China

Lead Time：1-3 Days

Condition：Brand New And Original

Warranty：1 Year

This product is imported from overseas, supports test report assistance, and smooth after-sales docking

The product inventory is continuously updated, and the order demand is quickly responded to. Welcome to call for consultation!

Product FAQs

We've listed some product-related issues below. If you need further information or technical support, please contact us via email or by submitting a form. We'll get back to you as soon as possible!

FAQs:

What is the input current range for the IC693ALG223D module?
The module supports three input ranges: 0 to 20 mA, 4 to 20 mA, and 4 to 20 mA Enhanced.

How many channels does the IC693ALG223D module support?
The module supports up to 16 channels, which are individually configurable.

What is the resolution of the IC693ALG223D module?
The resolution is 4 μA per bit for the 4 to 20 mA range and 5 μA per bit for the 0 to 20 mA and 4 to 20 mA Enhanced ranges.

What is the update rate of the IC693ALG223D module?
The update rate of the module is 6 milliseconds.

What is the power consumption of the IC693ALG223D module?
The module consumes 120 mA from the +5 VDC bus and 65 mA from the external 24 VDC supply.

What is the maximum isolation rating for the IC693ALG223D module?
The isolation is 250 VAC continuous and 1500 VAC for 1 minute.

How do I configure the IC693ALG223D module?
Configuration is done through the Proficy Machine Edition software, allowing you to set parameters such as input range, channel assignments, and alarm limits.

Can I use the IC693ALG223D module in hazardous locations?
Yes, the module is suitable for use in Class I, Division 2 hazardous locations, with proper installation and precautions.
