Bently Nevada 177230-01-02-CN Seismic (velocity) transmitter, loop-powered 100% New

Bently Nevada 177230-01-02-CN Seismic (velocity) transmitter, loop-powered 100% New

0.0

Points

100% Original and Authentic.
100% Brand New, Ready to ship.
Support Refund, 7X24h Service.
1-Year Warranty on All Products.

Today's Discount: 90% 00 : 00 : 00

Low stock: 38 left

25%

Add to cart

Product Details

Bently Nevada provides good Condition Monitoring and Machine Asset Protection. Power Supply, CPU, I/O Modules, Proximitor Sensor and Programming cable of 3500/33 are supplied.

Product Introduction

Bently Nevada 177230-01-02-CN Seismic (velocity) transmitter, loop-powered 100% New

Brand：Bently Nevada

Item No.：177230-01-02-CN

Product Type：Seismic (velocity) transmitter, loop-powered

Product Origin：USA

Dimensions：25.4 mm × 66.0 mm

Weight：0.131 kg

Payment：T/T, Western Union, Credit Card

Shipping Port：Xiamen, China

Lead Time：1-3 Days

Condition：Brand New And Original

Warranty：1 Year

Compliant import, support for cooperative testing, and fast response to after-sales service

Ten thousand models are in stock, quickly matching needs, welcome to call for cooperation!

Product FAQs

We've listed some product-related issues below. If you need further information or technical support, please contact us via email or by submitting a form. We'll get back to you as soon as possible!

FAQ

What does “01-02-CN” represent in the model number?
“01” indicates the measurement range option (0–25.4 mm/s), “02” represents the frequency response range (3 Hz–1 kHz), and “CN” designates Chinese and international hazardous area certifications.

Does the transmitter provide both dynamic and 4–20 mA outputs?
Yes. It provides a 4–20 mA loop output for vibration velocity (RMS) and an unbuffered dynamic voltage signal for detailed vibration analysis.

What supply voltage does the unit require?
The device operates with a 12–30 VDC supply and draws up to 40 mA.

How long does it take for the sensor to stabilize after power-up?
The transmitter settles within 2% of its final value in under 15 seconds.

Is any field calibration needed before installation?
No. The unit is factory calibrated and ready for use without additional configuration.

How is the sensor installed on the machine?
It mounts directly to the machine housing using a 1/4-28 UNF threaded hole to ensure solid mechanical coupling.

What are the physical dimensions and weight of the transmitter?
The overall size is Ø25.4 mm × 66.0 mm, and the weight is approximately 0.131 kg.

Can the 177230-01-02-CN be used in hazardous environments?
Yes. It is certified for use in explosive or hazardous areas under ATEX, IECEx, and NEPSI (China) standards.
